VCO-6000-CFL-1 Machine Vision Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x Expansion Slot

Product image 1
1 / 10
+5

VCO-6000-CFL-1 Machine Vision Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x Expansion Slot

  • Support 9th Gen IntelĀ® CFL-R S Processor (LGA 1151, 35W TDP)
  • IntelĀ® Q370 Chipset
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe (shared by 1x mSATA), and 2x SIM socket
  • 4x 2.5" SATA HDD Bay with RAID 0, 1, 5, 10 support, 1x mSATA (Shared by 1x Mini PCIe)
  • 1x M.2 (M Key, NVMe PCIe x4, 2280), 1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
  • 6x RS-232/422/485 (4x internal)
  • 4x USB 3.2 Gen 2 (10 Gbps), 5x USB 3.2 Gen 1 (5 Gbps, internal), 2x USB 2.0 header (internal)
  • 1x PCIe x16 (VCO-6000-CFL-1E) or 1x PCI (VCO-6000-CFL-1I)
  • 8x DI + 8x DO with isolation
  • 9 to 48V DC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature (-25Ā°C to 70Ā°C)
  • TPM 2.0 Supported
  • Support 9th Gen IntelĀ® CFL-R S Processor (LGA 1151, 35W TDP)
  • IntelĀ® Q370 Chipset
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe (shared by 1x mSATA), and 2x SIM socket
  • 4x 2.5" SATA HDD Bay with RAID 0, 1, 5, 10 support, 1x mSATA (Shared by 1x Mini PCIe)
  • 1x M.2 (M Key, NVMe PCIe x4, 2280), 1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
  • 6x RS-232/422/485 (4x internal)
  • 4x USB 3.2 Gen 2 (10 Gbps), 5x USB 3.2 Gen 1 (5 Gbps, internal), 2x USB 2.0 header (internal)
  • 1x PCIe x16 (VCO-6000-CFL-1E) or 1x PCI (VCO-6000-CFL-1I)
  • 8x DI + 8x DO with isolation
  • 9 to 48V DC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature (-25Ā°C to 70Ā°C)
  • TPM 2.0 Supported
$513.80

Original: $1,468.00

-65%
VCO-6000-CFL-1 Machine Vision Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x Expansion Slotā€”

$1,468.00

$513.80

Description

  • Support 9th Gen IntelĀ® CFL-R S Processor (LGA 1151, 35W TDP)
  • IntelĀ® Q370 Chipset
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe (shared by 1x mSATA), and 2x SIM socket
  • 4x 2.5" SATA HDD Bay with RAID 0, 1, 5, 10 support, 1x mSATA (Shared by 1x Mini PCIe)
  • 1x M.2 (M Key, NVMe PCIe x4, 2280), 1x M.2 (E Key, PCIe x2, USB 2.0, 2230, Support CNVi)
  • 6x RS-232/422/485 (4x internal)
  • 4x USB 3.2 Gen 2 (10 Gbps), 5x USB 3.2 Gen 1 (5 Gbps, internal), 2x USB 2.0 header (internal)
  • 1x PCIe x16 (VCO-6000-CFL-1E) or 1x PCI (VCO-6000-CFL-1I)
  • 8x DI + 8x DO with isolation
  • 9 to 48V DC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature (-25Ā°C to 70Ā°C)
  • TPM 2.0 Supported
