RCO-6111 Industrial Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x PCI/PCIe Expansion

Product image 1
1 / 12
+7

RCO-6111 Industrial Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x PCI/PCIe Expansion

  • LGA 1151 socket for 8th/9th Gen. IntelĀ® CFL-R S Processor (65W/35W TDP)
  • IntelĀ® Q370 chipset
  • 2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
  • 4x 2.5" SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
  • 1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, USB 2.0, 2230)
  • 6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
  • 8x DI + 8x DO with isolation
  • 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature -25Ā°C to 70Ā°C (35W CPU); -25Ā°C to 60Ā°C (65W CPU)
  • 1x PCIe x16 Expansion (RCO-6111E) or 1x PCI Expansion (RCO-6111P)
  • TPM 2.0 Supported
  • LGA 1151 socket for 8th/9th Gen. IntelĀ® CFL-R S Processor (65W/35W TDP)
  • IntelĀ® Q370 chipset
  • 2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
  • 4x 2.5" SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
  • 1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, USB 2.0, 2230)
  • 6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
  • 8x DI + 8x DO with isolation
  • 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature -25Ā°C to 70Ā°C (35W CPU); -25Ā°C to 60Ā°C (65W CPU)
  • 1x PCIe x16 Expansion (RCO-6111E) or 1x PCI Expansion (RCO-6111P)
  • TPM 2.0 Supported
$1,111.00
RCO-6111 Industrial Computer with 9th Gen IntelĀ® Coreā„¢ CFL-R S Processor, 1x PCI/PCIe Expansionā€”
$1,111.00

Description

  • LGA 1151 socket for 8th/9th Gen. IntelĀ® CFL-R S Processor (65W/35W TDP)
  • IntelĀ® Q370 chipset
  • 2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
  • Triple Independent Display by 1x DVI-I and 2x DisplayPort
  • 2x IntelĀ® GbE supporting Wake-on-LAN and PXE
  • 2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
  • 4x 2.5" SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
  • 1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, USB 2.0, 2230)
  • 6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
  • 8x DI + 8x DO with isolation
  • 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
  • Wide Operating Temperature -25Ā°C to 70Ā°C (35W CPU); -25Ā°C to 60Ā°C (65W CPU)
  • 1x PCIe x16 Expansion (RCO-6111E) or 1x PCI Expansion (RCO-6111P)
  • TPM 2.0 Supported
